The T8V is an affordable, professional 2-way powered studio monitor with an 8˝ woofer and ADAM Audio’s latest addition to the T Series. Designed around the same technology, features and build quality as its smaller siblings, the T8V provides best-in-class characteristics and sound performance.

The T8V impresses with a multitude of features that bring real benefits to the user: The U-ART tweeter’s 4:1 velocity transfer ratio, in combination with the new Class D amplifiers’ high dynamic range, yield respective max. peak SPL of 118 dB per pair. The tweeter, which extends up to 25 kHz, works as a team with the HPS Waveguide. This allows an optimal radiation of the high frequencies, which means the advantage of a more controlled, larger usable sweet spot during monitoring. With a bass extension down to 33 Hz, the T8V is especially suitable for users who produce bass-heavy music.

The T8V is the perfect studio speaker for those who have always wanted to work with an 8“ monitor from ADAM Audio, but where budgets have been insufficient. The 5-year warranty gives users additional security and the certainty of having purchased a quality product.

Key Features

U-ART 1.9” Accelerated Ribbon Tweeter with HPS Waveguide
Polypropylene 8” woofer and rear-firing bass-reflex port
Cumulated Amp. Power RMS: 90 W
Frequency Response: 33 Hz - 25 kHz (-6 dB)
Max. SPL Per Pair at 1 m: ≥118 dB

TECHNICAL DATA

WOOFER

Number	1
Basket Ø	8" (203 mm)
Voice Coil Ø	1" (26 mm)
Cone Material	Polypropylene

TWEETER

Number	1
Type	U-ART
Diaphragm Area	4 inch² (2420 mm²)
Equiv. Diaphragm Ø	1.9" (48 mm)
Velocity Transform Ratio	4:1
Diaphragm Weight	0.17 g
Waveguide	HPS

BUILT-IN AMPLIFIERS

Number	2
Woofer	1
Type	PWM
Amp. Power RMS	70 W
Tweeter	1
Type	PWM
Amp. Power RMS	20 W

CONTROL OPTIONS

Input Sensitivity	-10 to +4 dB
Gain	Yes
High Shelf EQ > 5 kHz	- 2 dB, 0 dB, +2 dB
Low Shelf EQ < 300 Hz	- 2 dB, 0 dB, +2 dB

INPUT CONNECTORS

Analog	XLR / RCA
Input Impedance	10 kOhm / 20 kOhm

GENERAL DATA

Panel	Rear
Frequency Response	33 Hz - 25 kHz (-6 dB)
THD > 80 Hz	0.5 %
Max. SPL per pair at 1 m	≥118 dB
Crossover Frequency	2.6 kHz
Max. Power Consumption	150 W
Weight	21.6 lb (9.8 kg)
Height x Width x Depth	15.8" x 9.8 “ x 13.2“ (400 mm x 250 mm x 335 mm)
Warranty	5 years (2 years warranty plus 3 years optional with product registration)
Delivery Contents	Power cord, Quick Start Guide
